Menics ASG-FF-B 86mm Beacon Light, 110/220V, Blue, Rotating

Menics 86mm Beacon Light, 110/220V, Blue, Rotating

Alternative Views:

Price: $41.29

Note: Delivery: 2-5 Business Days
MFG P/N: ASG-FF-B
MFG: Menics
Weight (lbs): 0.8

Quantity in Stock :3

Availability: In Stock
Product Code: ASG-FF-B

Qty:

Description

The Menics ASG-FF-B 86mm signal beacon light is 110/220V AC with a blue lens and an incandescent light. Rotates 130 times per minute. Stud mounted. Gear rotation provides a long motor life and exceptional visibility of light at long distances and in the dark. Useful in a wide range of applications such as in small machines, construction, and road safety. Rated IP 42. Note: See the link to our accessory chart below the description to find out which mounting accessories are compatible with each other.

Specifications

Mounting- Stud Mounting (see mounting accessories below)
Light & Bulb Type- Rotating Incandescent
Power Supply- 110/220V AC
Lens Color- Blue
Lens Material- Polycarbonate Resin
Buzzer- None
Current Draw- 0.4 Amps, 5 Watts
Brightness- 3 Lumens, 240 mcd (110V), 4 Lumens, 320 mcd (220V)
Rotation Rate- 130 times per minute
Dimensions- 143mm Height x 86mm Diameter (5.62" x 3.38")
Ambient Temperature- -15 C to 40 C (5 F to 104 F)
Storage Temperature- -25 C to 70 C (-13 F to 158 F)
Ambient Humidity- 45-85% Relative Humidity
Recommended Wire Size- VSF / 0.75mm² (Power supply wire only)
IP Protection- IP 42 (Protected against solid objects over 1.0 mm and falling drops of water, up to 15 degrees from vertical)
Approvals- RoHS, CE

Find out which mounting accessories you need with our Menics Signal Light Mounting Accessory Chart
