The ILME MAV-10L32 C-Type standard metallic hood is size 57.27 and features 2 pegs with an M32 cable entry. The body is epoxy coated die cast aluminum with cable entry through the top. Insert center distance: 57 x 27 mm (2.24" x 1.06"). Rated IP 66. The MAV-10L32 is durable and has a life expectancy over 500 cycles.

Specifications

Body- Epoxy Coated Die Cast Aluminum
ILME Series- MA
Insert Dimension- 57.27
Enclosure Dimension- 57.27
Housing Type- Metallic, Standard
Enclosure Type- Hoods for Single Lever
Mounting Style- Cable
Hood Entry- Top
Hood Thread- M32
Pegs- 2 Pegs
Temperature Range- -40 C to 125 C (-40 F to 257 F)
Ingress Protection- IP 66 (Total protection from dust and high pressure water jets from any direction)
Approvals- C UR US, CCC, GL

Compatible Inserts

Series	Part Number
CDD	CDDF-42, CDDM-42
CQE	CQEF-18, CQEM-18
CSH, CDSH	CSHF-10, CSHM-10, CDSHM-18, CDSHF-18, CMSHF-03, CMSHM-03
CCE	CCEF-10, CCEM-10
CNE, CSE	CNEF-10T, CNEM-10T, CNEF-10TX, CNEM-10TX CSEF-10, CSEM-10
CSS	CSSF-10, CSSM-10
CMSE	CMSEF-03, CMSEM-03
CMCE	CMCEF-03 CMCEM-03
CX	CXF-8/24, CXM-8/24

MAV-10L32 M32 57.27 Standard ILME Hood
