Mencom Panel Interface Connector, Duplex outlet, RJ11, RJ45, 3A reset

Mencom DP-RJ11-RJ45-R-32
Mencom Panel Interface Connector, Duplex outlet, RJ11, RJ45, 3A reset



Alternative Views:


Our Price: $138.35
MFG P/N: DP-RJ11-RJ45-R-32
MFG: Mencom
Weight (lbs): 1.45



Availability:
Delivery: Up to 7-10 Business Days
Product Code: DP-RJ11-RJ45-R-32
Qty:


Description


Mencom Panel Interface Connectors (PIC) mount to the outside of the control panel to allow access to the PLC or PAC without opening the control cabinet. The Mencom DP-RJ11-RJ45-R-32 PIC features a 120V Duplex Receptacle, RJ45 and RJ11 ports, and a 3 amp resettable fuse in a size 32 housing. Housing is rated NEMA/UL type 12, 4 & 4x and includes a lid, seal and latch.

Specifications

  • Body- Epoxy coated die cast aluminum
  • Gasket- Thermoplastic elastomer
  • Handle- Polyamide
  • Levers- Stainless Steel
  • Volts- 125 V
  • Amps- 3 A
  • SCCR- 10kA
  • Housing- Size 32 Bulkhead Housing
  • Power Ports- 120V Duplex Receptacle
  • RJ / Ethernet- RJ11 / RJ45
  • Fuse- 3 Amp Resettable
  • Ingress Protection- IP 66

DP-RJ11-RJ45-R-32 Mencom PIC with RJ45 and RJ11 Ports
