Mencom Panel Interface Connector, Duplex outlet, DB9, DB25, 3A reset


DP-DB9-DB25-R-32
Mencom DP-DB9-DB25-R-32 Panel Interface Connector, Duplex outlet, DB9, DB25, 3A reset

Alternative Views:


Price: $190.87
Note: Please call or email [email protected] for alternatives
MFG P/N: DP-DB9-DB25-R-32
MFG: Mencom
Weight (lbs): 1.5

Quantity in Stock :(Out of Stock)


Availability:
Out of Stock
Product Code: DP-DB9-DB25-R-32
Qty:


Description


Mencom Panel Interface Connectors (PIC) mount to the outside of the control panel and allow access to the PLC or PAC without having to open the control cabinet. The Mencom DP-DB9-DB25-R-32 PIC features a 120V Duplex Receptacle, a 9 Pin D-Sub, a 25 Pin D-Sub and a 3 Amp Resettable fuse in a size 32 housing. Housing is rated NEMA/UL type 12, 4 & 4x and includes a lid, seal and latch.

Specifications

  • Body- Epoxy coated die cast aluminum
  • Gasket- Thermoplastic elastomer
  • Handle- Polyamide
  • Levers- Stainless Steel
  • Volts- 125 V
  • Amps- 3 Amps
  • SCCR- 10kA
  • Housing- Size 32 Bulkhead Housing
  • Power Ports- 120V Duplex Receptacle
  • D-Sub- 9 & 25 Pin
  • Fuse- 3 Amp Resettable

Mencom Panel Interface Connector Part Number Guide

Mencom Panel Interface Connector Guide
