Menics PLDS-101-R 25 mm 1 Stack LED Tower Light, Steady, Red, 12V, Short Pole

Menics PLDS-101-R 1 Tier LED Tower Light, Red
Menics PLDS-101-R 1 Stack LED Tower Light, Red, Short Pole



Alternative Views:


Price: $51.96
MFG P/N: PLDS-101-R
MFG: Menics
Weight (lbs): 0.25

Quantity in Stock :2


Availability:
In Stock
Product Code: PLDS-101-R
Qty:

Description


The Menics PLDS-101-R 1 stack 12V LED tower light has a 25 mm diameter with a red lens and a steady light. Lens is prism cut, to provide an even light distribution. This PLD series light has a 65 mm anodized aluminum body and is useful for small device applications. The signal light itself comes pre-assembled, with a lead wire connection. Lock nut and fixing bolt for surface mounting included. Rated IP 52. Note: See the link to our accessory chart below the description to find out which mounting accessories are compatible with each other.

Specifications

  • Mounting- Surface Mount or Wall Mount (See wall mount bracket below)
  • Light Operation- Steady
  • Power Supply- 12V DC
  • Current Consumption- 0.07 Amps
  • Lens Colors- Red
  • Number of Tiers- 1 Stack
  • Lens Material- Polycarbonate Resin
  • Housing Material- Anodized Aluminum w/ ABS Plastic Cap
  • Hardware- Aluminum Fixing Bolt & Steel Lock Nut
  • Dimensions (Tower Light Only)- 121.5 mm Height x 25 mm Diameter (4.78" x 1")
  • Buzzer- None
  • Vibration- 0.75 mm @10~55Hz
  • Ambient Temperature- -15 C to 40 C (5 F to 104 F)
  • Storage Temperature- -20 C to 70 C (-4 F to 158 F)
  • Insulation Resistance- Over 100 MOhm (500V DC mega)
  • Ambient Humidity- 45-85% Relative Humidity
  • Recommended Wire Size- 1007 UL / 22 AWG
  • IP Protection- IP 52 (Protection from harmful dust deposits and water drops up to 15 degrees from vertical)
  • Approvals- CE, RoHS Compliant

Find out which mounting accessories you need with our Menics Signal Light Mounting Accessory Chart

PLDS-101-R 12V 1 Tier Red LED Tower Signal Light
