Sealcon CD21AS-02 high quality gray nylon cord grips are designed for the toughest applications. Accepts flat Romex cable. Also known as Hummel 1.587.2100.00. Sold Individually. Locking nut & O-Ring sold separately
Specifications
- Thread Size: PG 21
- Slot Size: .24" x .55" (6 x 14 mm)
- Through Hole Diameter: 1.12" (28.4 mm)
- Body Length: 1.22" (31 mm)
- Thread Length: .43" (11 mm)
- Wrench Flat Dome: 1.3" (33 mm)
- Wrench Flat Body: 1.3" (33 mm)
Features
- Nylon 6/6 Material with Elastomer Seal
- Operating Temperature: -40 C to 100 C (-40 F to 212 F)
- Submersible to 300 ft. / NEMA 4x & 6 (IP68)
- IP69K is possible, provided that there is an ideal fit and the O-Ring is used
- 150 psig (10 bar) Pressure Rating
- Flame Protected to UL 94
- Halogen and Phosphorous Free
- Vibration Resistant Dome
- Resists salt water, acids, alkalis', gasoline & oils.
- Durable Rugged Construction
- RoHS & Deca BDE, CSA approval
Approvals
- RoHS Compliance
- Deca Bde Deca-Bromo-Diphenyl-Ether Compliance
- Registration, Evaluation, Authorization and Restriction of
Chemicals
- Waste Electrical and Electronic Equipment Directive
- EAC
- CE
- German Lloyd
Sealcon PG 21 Nylon / Plastic Cord Grips, Strain Relief Fittings or Cable Glands are used to help customers in all industries connect their cable or wire to their applications. This fitting provides a NEMA 4x & 6 (IP 68 & 69K is possible, provided that there is an ideal fit and the O-Ring is used), 150 PSIG (10 bar) Liquid Tight Rating. It has an insert for flat cables and is made from Nylon with Elastomer form seal. Sealcon patented overlapping clamping splines, recessed custom grommets help protect your cable from damage and the elements. The CD21AS-02 fitting provides a substantial amount of Pull-out resistance by applying concentric force on all points of the cable. Romex is a registered trademark of Southwire Company.
Sealcon Gray Flat Cable Cord Grip with PG 21 Thread CD21AS-02
|
|
|
