The Menics AVGB-02-R 135mm signal beacon light is 24V DC with a red lens and an incandescent light. Rotates 150 times per minute. Stud mounted. Features 80 dB alarm. Has a belt friction type construction and offers exceptional visibility at long distances or in the dark. Perfect for applications such as large machines, road safety lights, and construction sites. Rated IP 42.
Note: See the link to our accessory chart below the description to find out which mounting accessories are compatible with each other.
Specifications
- Mounting- Stud Mounting (see mounting bracket below)
- Light & Bulb Type- Rotating Incandescent
- Power Supply- 24V DC
- Lens Color- Red
- Lens Material- Polycarbonate Resin
- Buzzer- Yes (see below for version without buzzer alarm)
- Current Draw- 1.04 Amps, 25 Watts
- Brightness- 45 Lumens, 3580 mcd
- Sound Level- 80 decibels (+/- 5) @1 meter
- Rotation Rate- 150 times per minute
- Dimensions- 166mm Height x 135mm Diameter (6.53" x 5.31")
- Ambient Temperature- -15 C to 40 C (5 F to 104 F)
- Storage Temperature- -20 C to 70 C (-4 F to 158 F)
- Ambient Humidity- 45-85% Relative Humidity
- Recommended Wire Size- UL1007, 22 AWG
- IP Protection- IP 42 (Protected against solid objects over 1.0 mm and falling drops of water, up to 15 degrees from vertical)
- Approvals- RoHS, UL, CE
Find out which mounting accessories you need with our Menics Signal Light Mounting Accessory Chart
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
