Overview
The
IMO Precision Controls SPS-1-092-24DC is a 92W single phase DIN rail power supply designed to convert a universal input of 85-264VAC or 120-370VDC into a regulated 24V DC output at 3.83 Amps. It is ideal for low voltage control circuits and industrial automation applications that require reliable DC power in a compact DIN rail mount design.Class 2DIN Rail Mount90% Efficient
With
90% efficiency, Class II isolation, and built-in overload and short circuit protection, this power supply is engineered for dependable operation in control panels and automation systems. Its modular plastic housing supports quick installation and efficient space use in industrial enclosures.
⚡ Reliable DC Power for Automation
Universal input range: Accepts 85-264VAC or 120-370VDC for flexible installation.
Stable 24V DC output: Supplies 3.83 Amps for low voltage control devices.
Protection built in: Includes short circuit, overload, and overvoltage protection for safer operation.
Key Features
- Delivers reliable DC power for automation circuits
- Suitable for common industrial control loads
- 90% efficiency: minimizes energy loss and heat generation
- Class II isolation: enhances electrical safety in control systems
- DIN rail modular design: simplifies installation in panels and enclosures
- Short circuit protection: hiccup mode safeguards against output faults
- 3 year manufacturer's warranty – dependable support from IMO Precision Controls
✅ Ideal Applications
The SPS-1-092-24DC is well suited for powering PLCs, sensors, relays, process controllers, HMIs, control panels, and automation systems that require stable 24V DC power from a compact DIN rail power supply.
Performance Benefits
🔒 Electrical Safety and Isolation
Class II isolation and a high isolation voltage rating of
3000VAC / 4242VDC help improve safety in industrial installations and support dependable separation between input and output circuits.
🛡️ Protection for Demanding Systems
This power supply includes short circuit protection in
hiccup mode, rated overload protection from 102 to 110%, and overvoltage protection from 30-36VDC to help protect connected equipment during abnormal conditions.
🌡️ Designed for Control Panels
Free air convection cooling, a compact housing, and a wide ambient operating range make this unit a practical choice for enclosed control cabinets and industrial automation panels.
⚠️ Installation Note
This unit is designed for
DIN rail mounting and uses a connector size range of AWG 24-12 (0.2-2.5mm²) for flexible or solid cable.
Proper ventilation and installation in accordance with applicable electrical codes are recommended.
Typical Applications
|
Recommended System Uses
|
|
PLCs / Controllers
|
Stable 24V DC power for logic and control circuits
|
|
Sensors / Relays
|
Reliable output for field and panel devices
|
|
HMIs / Process Control
|
DC power for operator interfaces and automation controls
|
|
Control Panels
|
Compact DIN rail power distribution inside enclosures
|
This power supply is designed for industrial automation environments that require efficient, compact, and protected 24V DC power conversion.
📦 Quick Purchasing Details
Part Number:
→ SPS-1-092-24DC
Power Output:
→ 92W
Output Rating:
→ 24V DC, 3.83 Amps
📌 Product Note
This Class 2 DIN rail power supply is intended for industrial control and automation systems that require dependable 24V DC output from a compact single phase unit.
