N-Tron 714FX6-ST Multimode, ST Style Managed Ethernet Switch, 2 KM

N-Tron 14 Port Managed Ethernet Switch
N-Tron Multimode, ST Style Managed Ethernet Switch, 2 KM - 714FX6-ST

Alternative Views:

Our Price: $3,032.00
Please Note: Call 800-966-2345 for quantity discounts
MFG P/N: 714FX6-ST
MFG: Red Lion
Weight (lbs): 1.8

Product Code: 714FX6-ST

Description Technical Specs Instructions & Manuals

The N-Tron 714FX6-ST by Red Lion is a compact fully managed fourteen port Industrial Ethernet Switch. Housed in a rugged DIN-Rail enclosure, it features 2km fiber optic multimode cable with an ST style fiber connector. The 714FX6-ST is made with reliability, noise immunity, strength and greater distance in mind and is especially useful in industrial and transportation applications.


  • (8) 10/100BaseTX RJ-45 Ports
  • (6) 100BaseFX Fiber Ports, ST Style
  • Onboard Temperature Sensor
  • Store-and-forward Technology
  • Auto Sensing 10/100BaseTX, Duplex, & MDIX
  • Redundant Power Inputs (10-49 VDC)
  • ESD & Surge Protection Diodes on all Ports
  • Configurable Bi-Color Fault Status LED
  • Rugged DIN-Rail Enclosure
  • SNMP v1, v2, v3 & Web Browser Management
  • Configuration Backup by Optional SD Card
  • Detailed Ring Map & Fault Location Charting
  • N-Ring Technology with ~30ms Healing
  • N-View OPC Monitoring
  • N-Link Redundant N-Ring Coupling
  • IGMP Auto Configuration
  • 802.1Q Tag VLAN and Port VLAN
  • 802.1p QoS, Port QoS & DSCP
  • Ethernet/IP CIP Messaging
  • Link Layer Discovery Protocol
  • Trunking
  • Port Mirroring
  • 802.1d, 802.1w, 802.1D RSTP
  • DHCP Server, Option 82 Relay, Option 61
  • Local Port IP Addressing

The N-TRON 714FX6-ST Industrial Ethernet Switch features eight 10/100BaseTX copper ports and six 100BaseFX fiber ports. The 714FX6-ST auto-negotiates the speed and performance capabilities of the TX port connections, and can be hard coded via the user interface. The 10/100BaseTX ports on the 714FX6-ST are auto sensing and auto configuring. A high speed processor permits wire speed capability simultaneously on all 100BaseTX ports. The 714FX6-ST has extended industrial specifications such as greater temperature range, greater shock & vibration specs, and redundant power inputs. The 714FX6-ST features management functions such as remote monitoring and N-Ring technology. The 714FX6-ST offers Web Browser as well as N-TRON N-View OLE for Process Control (OPC) Server Software. N-View can be combined with popular HMI software packages to add network traffic monitoring, trending and alarming to any application using N-TRON switches configured with the N-View option. SNMP is available for switch link and status monitoring. The status LEDs can be configured to respond to power failure and indicate N-Ring status. N-Ring Technology provides greater ring size capacity, detailed fault diagnostics, and a standard healing time of approximately 30ms. The 714FX6-ST Ring Manager checks the health of the Ring via packets. A ring map and fault location chart will be on the Ring Manager's web browser and OPC server that shows the current 'health status' of the Ring when all switches in the Ring are N-Tron fully managed switches.

Ethernet Switch with 6 ST Style Fiber Ports 714FX6-ST
