The Kacon KMSR-AS0254 single phase solid state relay has an input voltage of 90-265V AC & a load voltage of 90-480V AC. Load current of 25A. Features a hockey puck style housing and an LED indicates the status of the control input. The clip cover has a protection rating of IP 20 (Protected from objects 12.5 mm (0.5") in diameter or greater). Note: Image is for reference, actual part may differ.
Specifications
- Overall Dimensions- 58 mm Height x 45 mm Width x 32 mm Depth (2.28" x 1.77" x 1.26")
- Input Voltage- 90-265V AC
- Output Voltage- Single Phase AC
- Load Current- 25 Amps
- Load Voltage- 90-480V AC
- Pick-up Voltage- 72V AC Min
- Drop-out Voltage- 60V AC Max
- Input Current- 0.015 Amps Max
- Peak Voltage- 1200V
- Frequency- 47-63 Hz
- Single Cycle Surge Current Resistance- 250 Amps
- Output Leakage Current- 0.02 Amps
- Output on Voltage Drop- 1.8V Max
- Minimum Switching Current- 1 Amp
- Pick-up/Drop-out Time- 1/2 Cycle + 1 millisecond Max
- Insulation Resistance- 100 MOhms / 500V DC (between Terminal & Case)
- Dielectric Strength- 2500V AC (50/60Hz 1 minute)
- Vibration Resistance- 10-55Hz, Amplitude: 1.5mm,x,y,z each axis 2 hours
- Shock Resistance- 1000m/s2,s,y,z each axis 3 times
- Storage Temperature- -30 C to 90 C (-22 F to 194 F)
- Ambient Temperature- -25 C to 70 C (-13 F to 158 F)
- Ambient Humidity- 45-85% Relative Humidity
- Approvals- CE, UL & CUL Recognized
Kacon KMSR 25 Amp Solid State Relay
|
|
|
 |
|
 |
|
