Euri Lighting EALH-300W1033CWS 200–300W Selectable LED Area Light, 30,000–49,000 Lumens, 277–480V
High-output Type III LED area light with three selectable wattages, three selectable color temperatures, 1–10V dimming, wet-location construction, and an IP65 rating.
Why Choose the Euri Lighting EALH-300W1033CWS LED area light?
The Euri Lighting EALH-300W1033CWS is a selectable 200W, 240W, or 300W LED area light for parking lots and other outdoor areas. Operating on 277–480V input power, it delivers 30,000–49,000 lumens with Type III light distribution.
Installers can select 3000K, 4000K, or 5000K color temperature and use 1–10V dimming to match the site. The IP65-rated fixture is suitable for wet locations and has a rated life of 50,000 hours.
💡 30,000–49,000 Lumens
High-output illumination with model-specific output based on the selected wattage and color temperature
⚡ Three Wattage Settings
Select 200W, 240W, or 300W output for the installation
🎨 Three Color Temperatures
Choose 3000K, 4000K, or 5000K light from one fixture
🌧️ IP65 Wet-Location Rating
Protected from dust and low-pressure water jets from any direction
⚠️ Confirm Voltage, Mounting, and Accessories
This fixture requires a 277–480V input supply. Confirm the selected wattage, color temperature, Type III distribution, and fixture dimensions before ordering.
Mounting brackets, the optional motion sensor, and the remote control are sold separately.
🎛️ Selectable Output and Controls
The EALH-300W1033CWS provides three selectable wattages (200W, 240W, and 300) and three selectable color temperatures (3000K, 4000K, and 5000K). It also supports 1–10V dimming. Refer to the datasheet for the lumen output associated with each setting.
Key Features & Benefits
- Selectable 200W, 240W, or 300W LED area light
- Selectable 3000K, 4000K, or 5000K color temperature
- 1–10V dimmable
- Type III beam distribution
- Designed for parking lots and other outdoor areas
- Suitable for wet locations
- IP65-rated against dust and low-pressure water jets
- Mounting brackets, optional motion sensor, and remote control sold separately
Technical Specifications
| Brand |
Euri Lighting |
| Model Number |
EALH-300W1033CWS |
| Product Type |
Selectable LED Area Light |
| Dimensions |
20.05" L x 11.89" H x 2.07" D |
| Lumen Output |
30,000–49,000 lm; see datasheet for output by setting |
| Input Voltage |
277–480V |
| Selectable Wattages |
200W / 240W / 300W |
| Color Rendering Index (CRI) |
70 |
| Efficacy |
150–170 lm/W |
| Rated Life |
50,000 hours |
| Selectable Color Temperatures |
3000K / 4000K / 5000K |
| Replacement Rating |
750W / 1,000W |
| Beam Distribution |
Type III |
| Dimming |
1–10V |
| Operating Temperature |
-40°F to 113°F |
| Location Rating |
Wet locations |
| Ingress Protection |
IP65 |
| Approvals |
UL Listed; DLC Listed |
| Warranty |
5-Year Manufacturer's Warranty |
📋 Selection & Installation Checks
1. Verify Input Voltage: Confirm that the installation supplies 277–480V.
2. Select Wattage: Choose 200W, 240W, or 300W for the required output.
3. Select Color Temperature: Choose 3,000K, 4,000K, or 5,000K.
4. Confirm Distribution: Verify that Type III distribution matches the site layout.
5. Order Required Accessories: Mounting brackets, an optional motion sensor, and a remote control are sold separately.
📄 Euri Lighting EALH-300W1033CWS Downloads
Use the available product documents for model-specific installation and specification details.
✅ Ratings, Approvals, and Warranty
Location / Ingress Rating: Wet locations; IP65
Approvals: UL Listed and DLC Listed
Rated Life: 50,000 hours
Warranty: 5-Year Manufacturer's Warranty
|
|
|
 |
|
 |
|
