Mencom MDC-8FR-PCB M12 Receptacle, 8 Pole, Female Straight, 2A, M12

Alternative Views:

Price: $18.91

Note: Please call or email [email protected] for alternatives
MFG P/N: MDC-8FR-PCB
MFG: Mencom
Weight (lbs): 0.1

Quantity in Stock :(Out of Stock)

Availability: Out of Stock
Product Code: MDC-8FR-PCB

Qty:

Description

The Mencom MDC-8FR-PCB Micro DC (M12) female straight receptacle features an 8 Pin insert and M12 mounting thread size. The body is polyamide with gold plated copper alloy contacts. The MDC-8FR-PCB is rated at 60V. Rated IP 69. Operating temperature: -40 C to 105 C (-40 F to 221 F). Mencom MDC receptacles are known by their M12 size mating thread and single keyway. They provide plug and play solutions for various applications.

Specifications

Body- Polyamide
Shell- Nickel Plated Brass
Contacts- Gold Plated Copper Alloy
Rated Voltage- 60V
Rated Current- 2 Amps
Pin Count- 8
Ingress Protection- IP 69 (Total protection from dust as well as high pressure and high temperature water jets from any direction)
Orientation Head- Female Straight
Coupling Thread- Female
Mounting Thread- M12
Mating Thread- M12
Mounting Style- Front Mount
Nut- Yes
Termination- PCB
Approvals- UL & CUL Listed
