Mencom PCGU-M16 M16 0.117" - 0.39" (3 - 10 mm) O.D. Cable Gland, Gray

Mencom PCGU-M16 M16 Gray Strain Relief Fitting
Mencom PCGU-M16 M16 0.117" - 0.39" (3 - 10 mm) O.D. Cable Gland, Gray

Alternative Views:
Price: $1.97
Note: Delivery: 2-5 Business Days
MFG P/N: PCGU-M16
MFG: Mencom
Weight (lbs): 0.02

Quantity in Stock :261


Availability: In Stock
Product Code: PCGU-M16
Qty:


Description


Mencom PCGU-M16 gray plastic cable gland has M16 x 1.5 Thread. Accommodates 0.117" - 0.39" (3 - 10 mm) O.D. cable. Sold Individually. This cable gland has a dual grommet system to accommodate more cable sizes. For larger diameter cables, simply remove the inner seal from the outer seal. For smaller cables, no change to the strain relief is needed. Comes with locknut. Rated IP 68. UL & CUL Recognized. Note: PG 9 cable gland pictured

Specifications

  • Cord Grip Material - Polyamide
  • Inner Grommet- TPE
  • Outer Grommet- CR/NBR
  • Tightening Torque- 2 Nm
  • Temperature- -20 C to 100 C
  • Color - Gray
  • Mounting Thread- M16 x 1.5
  • Mounting Hole Clearance- 16.2 mm
  • Gland Upper Range- 0.39" (10mm)
  • Gland Lower Range- 0.117" (3mm)
  • Nut- Yes
  • Ingress Protection- IP 68 (Total protection from dust and prolonged immersion in water)
  • Approvals- UL & CUL Recognized
