ILME 830V Surface Mount Housing, Size 57.27, Double Lever, PG 16


ILME CMP-03.2
ILME CMP-03.2 830V Surface Mount Housing, Size 57.27, Double Lever, PG 16

Price: $52.65
MFG P/N: CMP-03.2
MFG: ILME
Weight (lbs): 0.8



Availability:
In Stock
Product Code: CMP-03.2
Qty:


Description


The ILME CMP-03.2 830V surface mount housing is size 57.27 and features a double lever with two PG 16 cable entries. The body is die cast aluminum with polyamide handles and stainless steel levers. Insert center distance: 57 x 27 mm. Rated IP 66 when attached and locked down. The CMP032 is made for use in high voltage applications.

Specifications

  • Body- Die Cast Aluminum
  • Gasket- Thermoplastic Elastomer
  • Handle- Polyamide
  • Lever- Stainless Steel
  • ILME Series- CM
  • Insert Dimension- 57.27
  • Enclosure Dimension- 57.27
  • Housing Type- Metallic, Insulated
  • Enclosure Type- 2 Levers
  • Mounting Style- Surface Mount
  • Temperature Range- -40 C to 125 C (-40 F to 257 F)
  • Gasket- Yes
  • Hood Entry- Side
  • Hood Thread- PG 16
  • Number of Entries- 2
  • Ingress Protection- IP 66 (Total protection from dust and high pressure water jets from any direction)
  • Insert Center Distance- 57 x 27 mm (2.24" x 1.06")
  • Approvals- UL, CUL, RoHS Compliant

Compatible Inserts

Series Part Number
CME CMEF-03T, CMEM-03T
